It consists of a self-gripping system replaced rope drum which provides a grip on the wire rope proportional to the load, ensuring that the wire rope is perfectly aligned to the pulley system, allowing the possibility of an unlimited endless height of lift.
Featuring a compact design this lightweight and portable wire rope hoist can be used on a variety lifting jobs such as construction, building, warehouse, elevators, mine, docks, industrial, marine platform etc.
* Unlimited lifting height, supplied with 30m, 50m, 100m, 150m, 200m rope length.
* Single line 300kg – double line 600kg lifting capacity.
* UP 11m/min and DOWN 15m/min lifting speed.
* Pendulum load lift in both directions allows to achieve 50% cost reductions.
* No squeeze, no mess, no damage of rope, longer working time.
* Fitted with a top hook for easy fitting onto clamp or trolley.
* Easy to change steel rope.
* Pendant control with Safety Emergency Stop Switch.
* Reduced maintenance.
Material Rope – UHMWPE Fiber Rope
Pendulum load lift in both directions allows to achieve 50% cost reductions.
* High Intensity: diameter 8mm has 1.2ton, diameter 11mm has 2.9ton.
* Light Weight: 30% density lower than nylon rope.
* Super Abrasion Resistance: ranks first among the plastic and even better than some of the metal.
* Outstanding Impact Resistance and Cut Resistance: strong ability to absorb energy.
* Anti-Aging: anti-ultraviolet radiation, anti-neutrons, particularly suitable for outdoor use.
* Excellent Insulation Properties
* Chemical Resistance
* Low Water Absorption
TUV/GS/CE/EMC ED 20% IP 54
A1 8000 Full Load Cycles
